HVAC (Heat Ventilation and Air Conditioning)
- HVAC single line Air flow as per GMP/ Required requirement.
- AHU Piping and Ducting layout drawing with proposed location of HVAC equipment.
- AHU Grouping, AHU filtration level drawing, room classification drawing.
- Designing qualification.
- Preparation of BOQ and estimate.
- General Agreement (GA) Drawing.
- Low humidity area specification, dehumidification drawing.
- Load calculation (latent load and Sensible load)
- Room required Air qty (CFM) designing.
- AHU/DHU location drawing.
Chiller
- Calculating chiller capacity
- Advantage of CHW system w.r.to DX system
- Operating cost analysis
- Energy recovery option
Ducting
- Duct Sizing
- Layout drawing / Ducting drawing
- Material of construction sheet
- Low leakage ducting
- Return riser + Supply air hepa terminal
Piping
- Pipe Sizing
- Quantity estimation
- Piping layout
- Material of construction
Load Estimation
AHU
- Heat load calculation
- Layout drawing
- Component selection – Fan, Filter, Motor, Coil
Dehumidifier
- Latent load calculation
- Dehumidifier sizing
- Energy Recovery
BOQ
- Capacity Tender document
- User Requirement sheet
- Overall cost estimation for HVAC
